Easy to use

Tilt Five® delivers the sci-fi dream of holographic gaming right on your table, without the absurd price tag. Plug the glasses into your PC or Android device and watch your favorite games come to holographic life.

See Tech Specs

Wicked Comfortable

Tilt Five’s glasses weigh 100 grams (30 to 80% less than typical mixed-reality headsets). Finally! Play immersive games all day – no more neck aches or eye strain.

See Tech Specs

Awesome Visuals

Tilt Five’s innovative optical system creates brilliant, vivid 3D realistic holographic images that rise from your table! The dynamic 720P and 110° FOV projectors make those wizards, armies, robots, and race cars feel like they’re really there on your table, ready to command.

See Tech Specs

Tubular 3D Sound

Stereo speakers and 3D spatial audio mean you can lean in and listen to characters and battles taking place anywhere on the board. With the built-in microphone for hands-free voice chat, you can discuss strategy with your team, wherever they are.

See Tech Specs

Hyper Immersive

Use the 6DOF wand to cast spells, pick up your holographic troops, or sculpt visually stunning worlds with millimeter precision. An embedded camera system tracks physical objects such as playing cards, game objects, and even your hands*! Games can blend real objects with virtual ones… you won’t be able to tell one from the other!

* hands sold separately

See Tech Specs

Multiplayer Ready

Share a holographic game night with friends at your home or online. Everyone with glasses has their own private view and sound. Don’t have enough glasses? No problem! Many of the multiplayer games support crossplay with their already vast audience of PC and Android players.

See Tech Specs

TILT FIVE™ TECH SPECS

How do holographic worlds, characters, and objects appear on your game table?

Glasses are for:
Projection

Form Factor

Weight: ~100g (~3.5 ounces) is great for all day gaming
Contact surface material: Silicone rubber (bio-compatible)
Fit: folding arms and adjustable nose bridge for a secure fit and comfort
Cable length: 1.5m (4.9 feet)

‍

Projection Optics

Dual HD 1280x720 LCOS pico-projectors
110 degree FOV delivers the widest view angle available in AR
85% efficient beam steering lenses
Brightness: 0.65 Lumens (more than enough to create super vivid, high-contrast images)

Camera Optics

Head Tracking (HT) Camera: 8-megapixel infrared camera to detect board & wand position as well as motion
Tangible Tracking (TT) Camera: 8-megapixel infrared programmable computer vision camera to detect objects and integrate them with the virtual projections

Tracking & Stabilization

Onboard Inertial Measurement Unit along with integrated tracking & image stabilization algorithms keep track of your head's movement relative to the gameboard
Intel Movidius chip for “reprojection” at 180 frames per second ensures a smooth framerate

Audio

Speakers: stereo speakers; one in each arm
Microphone: microphone for private chat
Audio over USB as composite device

Interface

USB 3.0 aka "SuperSpeed USB"
(what is USB 3.0?)
Connector: USB Type-C
Adapter: Each kit comes with a USB Type-C-to-A adapter (what is USB Type-C & Type-A?)
Connects to Windows PCs and Android devices (Android support coming soon)
Power: glasses draw power from the connected host device, no power components or batteries are required, leaving the glasses lightweight
Bluetooth connection to wand

GAMEBOARD IS FOR:
rEFLECTION

Form Factor

XE BOARD:

Weight: 2.2 kg (4.9 lbs)
Folded: 266.67mm x 400mm (10.5" x 15.75")
Unfolded: 800mm x 1066.7mm (31.5" x 42")
Optional kickstand elevates back 1/4 of the board by 45 degrees

TRACKING

Tracking markers (aka fiducial markers) help keep glasses’ images bound to board with fixed precision

‍

MATERIAL

The gameboard is a spherical retroreflector, which returns the projected images from the glasses directly back to the wearer's eyes
Retroreflector-based AR keeps images in focus at correct distances (and solves the Vergence-Accommodation Conflict endemic to nearly all VR and AR headsets)
The gameboard is a passive material and all of the projection power comes via the glasses
Luminance: 280cd/1x.m

wAND IS FOR:
DIRECTION

FORM FACTOR

Our wand is designed to look and feel comfortable yet familiar, like any household tool, while also fulfilling that fantasy of wielding a real magic wand!
Dimensions: 47mm x 320mm x 38mm
(1.85" x 12.6" x 1.5")
Weight: 88 grams (3.1 ounces)

tRACKING

6-degrees-of-freedom (aka 6DOF) tracking achieved by combination of wand's onboard Inertial Measurement Unit and infrared tracking system between the wand and glasses

INPUTS

Your wand's position and movement is tracked in 3D space in relation to your glasses and gameboard
The wand has two orientations: an upright magic wand orientation and a sideways orientation for classic console controls
Wand Inputs: trigger, joystick, 7 buttons (A, B, X, Y, 1, 2, System)

iNTERFACE

Bluetooth connection to glasses
LED status indicates power and pairing status with the glasses
Power: Two (2) AA batteries required
Haptic motor inside the wand adds tactile feedback through the use of vibrations

Glasses are for:
Projection

FORM FACTOR

Weight: ~100g (~3.5 ounces) is great for all day gaming
Contact surface material: Silicone rubber (bio-compatible)
Fit: folding arms and adjustable nose bridge for a secure fit and comfort
Cable length: 1.5m (4.9 feet)

Projection Optics

Dual HD 1280x720 LCOS pico-projectors
110 degree FOV delivers the widest view angle available in AR
85% efficient beam steering lenses
Brightness: 0.65 Lumens (more than enough to create super vivid, high-contrast images)

Camera optics

Head Tracking (HT) Camera: 8-megapixel infrared camera to detect board & wand position as well as motion
Tangible Tracking (TT) Camera: 8-megapixel infrared programmable computer vision camera to detect objects and integrate them with the virtual projections

Tracking & Stabilization

Onboard Inertial Measurement Unit along with integrated tracking & image stabilization algorithms keep track of your head's movement relative to the gameboard
Intel Movidius chip for “reprojection” at 180 frames per second ensures a smooth framerate

Audio

Speakers: stereo speakers; one in each arm
Microphone: microphone for private chat
Audio over USB as composite device

Interface

USB 3.0 aka "SuperSpeed USB"
(what is USB 3.0?)
Connector: USB Type-C
Adapter: Each kit comes with a USB Type-C-to-A adapter (what is USB Type-C & Type-A?)
Connects to Windows PCs and Android devices (Android support coming soon)
Power: glasses draw power from the connected host device, no power components or batteries are required, leaving the glasses lightweight
Bluetooth connection to wand

GAMEBOARD IS FOR:
rEFLECTION

FORM FACTOR

XE BOARD:

Weight: 2.2 kg (4.9 lbs)
Folded: 266.67mm x 400mm (10.5" x 15.75")
Unfolded: 800mm x 1066.7mm (31.5" x 42")
Optional kickstand elevates back 1/4 of the board by 45 degrees

Tracking

Tracking markers (aka fiducial markers) help keep glasses’ images bound to board with fixed precision

Material

The gameboard is a spherical retroreflector, which returns the projected images from the glasses directly back to the wearer's eyes
Retroreflector-based AR keeps images in focus at correct distances (and solves the Vergence-Accommodation Conflict endemic to nearly all VR and AR headsets)
The gameboard is a passive material and all of the projection power comes via the glasses
Luminance: 280cd/1x.m

wAND IS FOR:
DIRECTION

Projection Optics

Our wand is designed to look and feel comfortable yet familiar, like any household tool, while also fulfilling that fantasy of wielding a real magic wand!
Dimensions: 47mm x 320mm x 38mm
(1.85" x 12.6" x 1.5")
Weight: 88 grams (3.1 ounces)

Tracking

6-degrees-of-freedom (aka 6DOF) tracking achieved by combination of wand's onboard Inertial Measurement Unit and infrared tracking system between the wand and glasses

interface

Bluetooth connection to glasses
LED status indicates power and pairing status with the glasses
Power: Two (2) AA batteries required
Haptic motor inside the wand adds tactile feedback through the use of vibrations

Inputs

Your wand's position and movement is tracked in 3D space in relation to your glasses and gameboard
The wand has two orientations: an upright magic wand orientation and a sideways orientation for classic console controls
Wand Inputs: trigger, joystick, 7 buttons (A, B, X, Y, 1, 2, System)
